Vmc 1165 CNC Vertical 3 Axis Milling Machine Center
Specification TRAVELX/Y/Z axis travel1150x660x600mmSpindle nose to table120-720mmSpindle center to column710mmPositioning accuracy±0.003/300mmRepeated positioning±0.002/300mmSpindleSpindle taperBBT40Spindle transmissionDirect driveSpindle speed12000 rpm/minControllerCNC contr......
Send Inquiry
Product Description
Specification
Main parts list:
Optional configuration:
- SIEMENS/FANUC/Mitsubishi CNC Controller
- 4th/5th axes rotary table
- Chip conveyor
- Tool setter
- Oil mist collector
| TRAVEL | |
| X/Y/Z axis travel | 1150x660x600mm |
| Spindle nose to table | 120-720mm |
| Spindle center to column | 710mm |
| Positioning accuracy | ±0.003/300mm |
| Repeated positioning | ±0.002/300mm |
| Spindle | |
| Spindle taper | BBT40 |
| Spindle transmission | Direct drive |
| Spindle speed | 12000 rpm/min |
| Controller | |
| CNC control | Fanuc 0i-MF |
| Spindle motor | 11/15 kw 12000 rpm/min |
| X/Y/Z motor | 3.0/3.0/3.0kw |
| Table | |
| Table size ( W x L ) | 1250x650mm |
| T slot | 5-18x100mm |
| Table load | 1100kg |
| Feed | |
| X/Y/Z rapid feed rate | 30/30/30m/min |
| X/Y/Z linear guideway | Roller type 45/45/45 |
| X/Y/Z ball screw | 10mm-ball |
| MACHINE DIMENSION | |
| Dimension | 3100x2550x2550mm |
| Weight | 8000kg |
Main parts list:
| Item | Brand |
| Spindle | Taiwan-Spintrue |
| Spindle bearing | Japan-NSK |
| Ball screw | Taiwan-HIWIN-C3 |
| Linear guideway | Taiwan-HIWIN |
| Pneumatic parts | Taiwan-Mindman |
| Electric parts | Japan-Mitsubishi/Omron |
Optional configuration:
- SIEMENS/FANUC/Mitsubishi CNC Controller
- 4th/5th axes rotary table
- Chip conveyor
- Tool setter
- Oil mist collector
